Products
Compact liquid-cooled braking resistors for light rail and trams (CBW)
Danotherm CBW liquid-cooled resistors deliver compact high-energy absorption for rail applications with high average power or pulse loads. In light rail and tram braking systems, the liquid-cooled design saves space compared with air-cooled alternatives and can enable regenerated braking heat to pre-heat driver or passenger compartments.
Key benefits
- Small dimensions versus air-cooled types
- High pulse-load capability
- High vibration withstand capability
- Optional thermal switch or PT100 sensor
- Customized cable shoe connectors or DIN-rail terminals
- Regenerated heat can be reused for compartment heating
Technical specifications
Power................................. | From 860 W |
Working voltage................. | 1000 VAC / 1400 VDC |
Overload............................. | Up to 60 × nominal power over 5 s/hour depending on resistance |
Protection ratings............... | IP50–IP65 |
Termination....................... | Box or stud termination |
Certifications / standards: Designed to project requirements; series approvals to be confirmed per selected design before publication.
More information: Danotherm.com External link.
